R32 Thread Button Bit, 51 mm – Spherical Carbide Inserts

R32 threaded button bit, 51 mm diameter, spherical tungsten carbide inserts for hard and abrasive rock.

SKU: BB-R32-051

Description

R32 Thread Button Bit — 51 mm

Threaded button bit for top hammer rock drilling in medium-hard to hard formations. The bit body is machined from heat-treated alloy steel and fitted with spherical tungsten carbide inserts pressed into precision-drilled holes.

Specification

Thread: R32 (also available in R25, R28, R38, T38, T45, T51)
Bit diameter: 51 mm
Insert shape: Spherical — recommended for hard and abrasive rock
Bit face: Flat face / drop centre (optional)
Body material: Heat-treated alloy steel
Inserts: Tungsten carbide

Application

Bench drilling, production drilling and tunnelling with hydraulic or pneumatic rock drills. Spherical inserts give the longest service life in hard, abrasive rock; ballistic inserts penetrate faster in softer formations.

Ordering

Specify thread size, bit diameter, insert shape and quantity. OEM markings, custom insert grades and private-label packaging are available on request.

Additional information

Thread Size	R32
Bit Diameter	51 mm
Bit Type	Button Bit
Carbide Insert Shape	Spherical
Material	Tungsten Carbide
Application	Mining, Quarrying, Tunneling
Compatible Machine	Atlas Copco, Sandvik
